Lancia Delta HF Intergrale 8v & 16v, Fiat Coupe Turbo & Alfa Romeo 2.0L 16v Turbo, Std. Diameter
CHF 348.19 inkl. MwSt.
Material:
F780
Motorcode:
AR06476, AR33601, AR67203, AR67501, AR67502, 146 B.000, 146 B3.000, 146 D7.000, 149 B5.046, 154 A1.000, 154 A2.000, 154 B.000, 154 C4.000, 154 C4.046, 154 C5.000, 154 C6.000, 154 D1.000, 154 E1.000, 160 A5.000, 160 A6.000, 160 A6.046, 160 A8.046, 160 B6.046, 175 A1.000, 176 A3.000, 176 A5.000, 176 B7.000, 178 C9.000, 230 A3.000, 230 A4.000, 280 A1.000, 160 D1.000, 175 A4.000, 831 A7.000, 831 B3.000, 831 B5.000, 831 B7.046, 831 C5.000, 831 C5.046, 831 D.000, 831 D1.000, 831 D5.000, 831 E5.000, 831 E5.046, 834 C.000, 834 C.146, 834 C1.000, 834 C1.246, 834 F1.000, 834 F2.000, 835 A4.000, 835 A4.046, 835 A5.046, 835 A7.000, 835 A7.046, 835 A8.000, 835 A8.046, 836 A2.000, 836 A3.000, 838 A4.000
Half type:
Identical halves
Max overall Length:
20,75 mm / 0.8169 in (2908H) // 24,25 mm / 0.9547 in (2909H)
Max. Std. Shaft size:
53 mm / 2.0866 in
Max. Std. Tunnel size:
56.735 mm / 2.2337 in
Max. wall at crown:
1.843 mm / 0.0726 in
Min. Std. Shaft size:
52.991 mm / 2.0863 in
Min. Std. tunnel size:
56.717 mm / 2.2329 in
